21000BPH 500ml Automatic Bottle Unscrambler For Unscrambling And Sorting

21000BPH 500ml Automatic Bottle Unscrambler For Unscrambling And Sorting ​Automatic Bottle Unscrambler 21000BPH (500ml) for Unscrambling and sorting PET bottles

Specifications:

Model: LP-21
workstations: 21
Rated capacity: 21000BPH (500ml)
Air pressure: 0.7MPa
Gas consumption: 2M3/ min
bottle: diameter 50－96,height 165－310mm
Main motor power: 3KW
Elevator power: 0.75KW
Main machine overall : Φ2640×2340(diameter ×height)
Main machine weight: 4200Kg

Description:

LP series bottle unscrambler is based on advanced foreign technology, according to requirements of beverage filling equipment high speed development, develop a domestic leading level bottle unscramble equipment.

Applications:

Unscrambling and sorting PET bottles

Main characteristic

• Main motor reducer adopts torque limit institutions, to prevent failure damaged machine.
• Adopt hang bottle neck air conveyor, to prevent turnover when conveying.
• The bottle unscrambler has stuck bottles detector, if bottle stuck, it will stop automatically and alarm.
• The bottle unscrambler has no bottle detector, which used for sending work signal to the elevator, the elevator will supply bottle automatically.
• Air conveyor has photoelectric switch, which control the start-stop of bottle unscrambler.
• With maintenance door and mold changing door.
• The main electrical component (transducer, PLC, photoelectric switch, relay) use Mitsubishi, Omron, Siemens and other famous brands.
• Pneumatic circuit adopt international brand product.

Specification

• Touch screen: Thinget
• Inverter: Mitsubishi
• PLC: Mitsubishi
• Pneumatic cylinder: Airtac
• Contactor & switch: Schneider
• Photoelectrical switch: Autonics
• Motor: Tekong or Siemens

water treatment machine

Water Treatment Equipment

21000BPH 500ml Automatic Bottle Unscrambler For Unscrambling And Sorting Images
